Product Description
CNC computer engraving machine plays an important role in modern manufacturing industry. This engraving machine is able to accurately carve digital design patterns on a variety of materials, such as metal, wood, plastic, etc., so as to achieve efficient production and manufacturing.
CNC computer engraving machine using computer control system to operate, with a high degree of automation and intelligent characteristics. It is simple to operate, easy to maintain and energy saving and environmental protection, the operator only needs to operate through computer software, and does not need to carry out complex machine and equipment operation and adjustment.
As a high-tech industrial equipment, CNC computer engraving machine will play a more important role in the future manufacturing industry. With the continuous progress and update of technology, it will provide more convenient and efficient services for production and manufacturing. In the pursuit of high quality, high efficiency and high competitiveness today, CNC computer engraving machine will become the preferred equipment for more and more enterprises.
CNC computer engraving machine Scope of application
1. Woodworking industry: three-dimensional wave plate processing, wooden doors, screens, craft window processing, auxiliary processing of various furniture products.
2. Advertising industry: advertising signs, sign production, acrylic cutting, blister molding, a variety of materials advertising products production.
3. Mold industry: can carve copper, aluminum, iron and other metal molds, as well as marble, plastic board, wood and other non-metal molds.
4. Other industries: can carve a variety of shadow carving, relief, widely used in the craft gift industry.
Products Description
The roller screw runs smoothly
At the same time, it has the characteristics of high precision retrograde and high efficiency.
The spindle adopts high-strength spindle and cutter head to work for a long time to reduce the loss, and the imported bearing has high speed and low noise, high speed, and the water swinging structure at the front end of the saw effectively prevents water and dust from entering the motor.
Guideway + helical rack Imported square guideway with high-precision German process grinding helical rack, the accuracy is greatly improved to ensure that long-term work is not affected (high dust, 2000 km maintenance-free, easy maintenance.
Square steel gantry: The use of heat treatment of one centimeter thick square steel gantry, gantry overall planer steel good operation more stable, higher machine accuracy.
CNC computer engraving machine Technical Parameters
|
Principal axis |
water cooled spindle 3.2kw/4.5kw/5.5kw/6kw |
|
Processing area |
1300*2500mm*200mm/Can be customize |
|
Work platform |
Welding 4mm Steel platform |
|
Machining precision |
±0.03mm (Less than 0.03mm) |
|
Repeated position accuracy |
±0.02mm |
|
Longmen structure |
Thickened square steel gantry |
|
Material fixation |
Vacuum adsorption with motor 5.5KW(optional 7.5 KW) |
|
XYZ structure |
X shaft slanting rack, Y shaft slanting rack, Z axis screw(+25 square rail) |
|
X/Y axis |
25 square rail/ helical rack |
|
Z axis |
High precision TBI ball screw |
|
Control System |
DSP A11 |
|
Command Language |
G code |
|
Spindle Speed |
6000-24000/min |
|
Drive Motors |
Stepper motor 450B and Leadshine 860H driver |
|
Table Surface |
Vacuum table with T-slot combined( T-slot table optional) |
FAQ
Q: What's your advantage?
Q: How I believe you?
Delivery photo
CNC computer engraving machine After-sales service
In the company has professional technical personnel to do after-sales, since the day of receiving the machine, please the user automatically ask for the factory's technical after-sales phone, since the user in the process of using all the technical problems about the machine, after-sales will teach you how to use, to help you solve all the technical problems about the machine, in addition to technology, other problems encountered by the user can find the store to discuss the solution.
